LS VISION 2 Megapixel Solar Power Outdoor Security Wireless 3G 4G Live View Sim Card IP GSM Solar Camera

  • 1 - 49 Pieces
    $119.95
  • 50 - 99 Pieces
    $114.95
  • >=100 Pieces
    $109.99
Type:
4G Solar Wifi Camera
Style:
Bullet Camera
Resolution:
1920 x 1080
Lead Time:
Quantity(Pieces) 1 - 20 21 - 50 51 - 100 >100
Est. Time(days) 8 12 18 Negotiable
Customization:
Customized logo (Min. Order: 50 Pieces)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
LS VISION
Model Number:
LS-MB6200S
Sensor:
CMOS
Special Features:
Waterproof / Weatherproof
Key Feature1:
4G Solar powered security camera system
Key Feature2:
1/2.8" Sony IMX307 Starlight sensor 0.001LUX
Key Feature3:
Support WIFI function
IR distance:
30-50 meters
Interface protocol:
onvif
Digital enlarge:
Can achieve through NVR, P2P HD monitoring management software
Storage:
Support TF card storage 128G
Imageing compression:
H.265/H.264
DNR:
3D-DNR
Work environment:
35℃; - 60℃, humidity is less than 95% (no condensation)
Supply Ability
Supply Ability:
5000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
color box/carton
Port
shenzhen
Lead Time :
Quantity(Pieces) 1 - 20 21 - 50 51 - 100 >100
Est. Time(days) 8 12 18 To be negotiated
Video Description
More Recommendation
Product Description

LS VISION 2 Megapixel Solar Power Outdoor Security Wireless 3G 4G Live View Sim Card IP GSM Solar Camera


4 G /3G Features:

1)Use of industrial 4G module, stable, long life,Anti-interference ability;
2)4G main chip :ZX297520M, WIFI chip:RTL8192ES-CG
3)4G all Netcom, support telecommunications, Unicom, mobile 4G / 3G / 2G, support Europe \ US \ Japan \ African 4G standards;
4)Network type :FDD-LTE, TDD-LTE, WCDMA/HSPA+, TD-SCDMA, GSM/GPRS/EDGE
5)Operating frequency :LTE B1/B3/B8/B38/B39/B40/B41,WCDMA,2100/900MHz,TD-SCDMA B34/B39,GSM/GPRS/EDGE: 900/ 1800MHz
6)Rate:FDD-LTE/TDD-LTE:up speed 50M / down speed 150Mbps
HSPA+:up speed 5.76M / down speed 21Mbps
TD-SCDMA: up speed 2.2Mbps / down speed 2.8Mbps
7)Support network equipment using wired and wireless WIFI two access methods
8)WiFi:2412MHz-2472MHz,802.11b/g/n,The maximum transfer rate is up to 72Mbp
9)USIM/SIM card :Micro SIM card
10)Built-in WEB client, Can view the 4G signal strength, modify the login password, wireless access password and others



IP camera Features:
1)Professional design for 4G/3G IP camera, easy assembly 4G card and TF card
2)3.0 megapixel HD lens + IR-CUT auto swith in day and night, 3.6mm/6mm lens, 2.8-12mm and 6-22mm auto focus lens as optional
3)Support 3D DNR, auto white balance, auto electronic shutter, auto electronic gain, real color reproduction, high resolution image;
4)Standard SD/TF memory card slot (support 64G card);
5)Standard 1 X 5DB 4G antenna, one 5DB WIFI antenna;
6)Power consumption: : day 4W / night 12W, the day power consumption of about 12V 16AH
7)Support P2P remote check
8)Optional function: two way audio , pan tilt rotating bracket
9)Support ONVIF protocol, can provide the SDK


Key Features:


1. all aluminum alloy, on the flip cover, easy disassembly 4G card and TF card;
2. 4 high-power dot matrix light source, effective night vision distance of 50 meters;
3. built-in all-Netcom 4G module, comes with wireless routing function;
4. comes standard with TF memory card slot (supports 64G card);
5. standard 2x5DB 4G antenna, 1x5DB WIFI antenna;
6. Optional: audio, zoom lens, rotating bracket;
7. software: P2P remote, low code cloud platform (support WeChat live);
8. power consumption: day 4W / night 12W, the day power consumption of about 12V16AH;
9. Product Size: 212mm × 108mm × 75mm;
11. Standard lens: 3.6mm,Lens Optional:2.8-12mm,6-22mm.

12. Optional: audio, motorized zoom lens, rotating bracket



* Optional: Audio, Motorized Zoom Lens, Rotating Bracket,
* Lens Optional: 2.8-12mm: add $16.00; 6-22mm: add $20.00; Built-in pickup and speaker: add $5.00;


* Note: standard only solar camera, standard without solar panel + lithium battery + Bracket, if you need full set with solar panel, battery and bracket, please contact us for Extra purchase.

with Bracket, Battery and Solar Panel

solar panels with metal wall bracket, with duckbill stent can be
adjusted to the direction of solar energy
→ solar photovoltaic board size: 50W: 630*540*18mm
→ Bracket size: 700*430*30mm

Solar Camera with Rotating bracket

255 degree horizontal rotation, 60 degree vertical rotation
Note: Rotating brackets are not supported if the camera is equipped
with a solar panel with LS-K5020&LS-K7030.(Unable to install)
Specification
Product
LS-MB6200S 4G Solar Security Ip Camera
Single system
PAL / NTSC adjustable
Sensor
Hi3516E + 1 / 2.8"Sony IMX307 Starlight sensor 0.001LUX
Scanning mode
Progressive scanning
Lens
Standard with 2.0 megapixel, 3.6mm lens
Day and night switch
IR-CUT dual optical filters auto switch in day and night
Electronic shutter
Manual / auto ( adjustable, 1 / 25 ~ 1 / 4000 seconds)
White balance
Auto / manual
DNR
3D-DNR
IR source
4pcs array IR
IR distance
100 meters
FDD-LTE
B1/B2/B3/B4/B7/B8/B12/B13B/B18/B19/B20/B26
TDD-LTE
B38/B39/B40/B41
WCDMA/TD-SCDMA
B1/B2/B4/B5/B8/B34/B39
GSM/GPRS/EDGE
900/ 1800MHz
Imageing compression
H.264
Video bit rate
128 Kbps -- 8 Mbps; CBR / VBR adjustable
Max image size
1920x1080
Frame size
1920 x 1080 @ 30 fps;1280 x 960 @ 30 fps; 1280 x 720 @ 30 fps; 704 x 576 @ 25 fps; 640 x 360 @ 25 fps; 352 x 88 @ 25 fps
Image adjustment
Through IE can adjust Saturation,brightness, contrast,sharpness
Image mirroring
Horizontal mirroring, vertical mirroring
scene
Auto, indoor, outdoor
Digital enlarge
Can achieve through NVR, P2P HDmonitoring management software
Storage
Support TF card storage 64G
Interface protocol
onvif
Support protocol
TCP / IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS,
Intelligent alarm
Motion detection, mask alarm, network cable
wifi
Support WIFI function
Communication interface
1pc RJ45 10M / 100M Adaptive Ethernet port
Power input
DC 12V±10%
Power mption
4W (IR off) / 9.8 W (IR on)
Work environment
35℃; - 60℃, humidity is less than 95% (no condensation)
size
183mm*91mm*66mm
Certification
