LSVISION 1080P NVR Kit 4ch Cloud Video Recorder WIFI System

FOB Reference Price:Get Latest Price
$113.00 - $123.00 / Piece | 1 Piece/Pieces (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
LS VISION
Model Number:
LS-NFWK8104
Bidirectional Talk:
1 CH(Line in,2Vpp,1Kohms)
Network Interface:
1 RJ45 10M / 100M adaptive Ethernet interface
IP Resolution:
1920*1080
Synchronous Playback:
Up to 8CH
SATA:
1
ESATA:
0
USB:
2 USB 2.0 Interfaces
Playback simultaneously:
1-8 CH optional
Dimensions:
360*260*48mm(W*D*H)
POE interface:
N/A
Supply Ability
Supply Ability:
3000 Piece/Pieces per Week WIFI NVR KIT
Packaging & Delivery
Packaging Details
4 sets /CTN
CTN size: 690X560X520mm
5000g/pc
Port
Shenzhen
Lead Time :
3 to 7 working days
Specification

4CH 960P WIFI NVR Kit                          Model :LS-NFWK8104


Key Features:


4CH 960P wifi NVR + 4pcs 960P wifi IP cameras

Convenient Installation

Plug and play

P2P, offer friendly APP

Support 1 SATA HDD

Wireless transmission stability:2.4G wireless

960P HD Video

Special and separate network for wireless transmission

Wifi wild working distance up to 60M

Quick setup, with built-in multilingual management page

Model
LS-NFWK8104
Operating System
Embedded Linux OS
 AV(video)input
DSP
Hi3520D
Network Video
4CH
Network video input broad bank
10Mbps
     AV (video) output
HDMI input
1ch,resolution:1024x768,1366x768,1440x900,1920x1080p
VGA output
1ch,resolution:1024x768,1366x768,1440x900,1920x1080p
AV CODEC Specification
Video Resolution
D1/960P
synch-playback
4CH
 Video Control
Video/Capture mode
Manual、Time、Motion、Alarm
Playback mode
Real time、Routine、Event
Backup
USB backup
Alarm
Alarm Input
4ch (optional)
Alarm Output
1ch (optional)
Hard Disk
Type
1*SATA interface
Max Capacity
4 TB at most for each
External Interface
Network Interface
1 adaptable RJ45 10M/100M, 1 WIFI interface
USB Interface
2 USB 2.0
Network Control
Protocol
UPnP (play&plug)/SMTP (email survice)/PPPoE (dial-up)
DHCP (Automatically obtain an IP address), etc…
Others
Power Supply
DC12V3A
Power Consumption (W)
≤5W(Without HDD)
Operate Temperature (°C)
-10℃~+55℃
Working Humidity (%) RH
10%~90%
Size
257mm(W)×210mm(V)×45mm(H)
Weight(excluding HDD)
≤1Kg
IPC Specification:
Model
/
Sensor
1/3” Progressive Scan Sensor
DSP
Hi3518E+STW1135
Signal System
PAL/NTSC
Resolution
960P; 1280 x 960 16 : 9 High Defination
Minimum illumination
Color: 0.1 Lux; B/W: 0.01 Lux
Shutter
1/25s to 1/25,000s
Lens
3.6/4/6mm (optional)
OSD
Date Time & Title
White Balance
Auto
Day&Night
Auto / Color / BW
3D-DNR
Auto
Mirror/Flip
On / Off
Frame Specification
Three Streaming at the Same Time:

H.264 1280x960@30fps or belowH.264 640x480@30fps or below
Below
S/N
> 39.1 Db
Interface
RJ45 / WIFI 802.11b/g/n
General Specification
Anti-thunder Level
Standard IEC61000-4-5
Ambient

Temperature/Humidity
-10℃ to +50℃ / 30% to 80% RH
Working Temperature/Humidity
-20℃ to +60℃ / 20% to 90% RH
Power Input
DC12V-1A
Power consumption
≤6W
Size
205(L)×70(W)×55 (H)mm
Weight
0.5Kg
Level of Protection
IP66
LS VISION Info

Why LS VISION will be your first choice in the market?



LS VISION Technology Co., Ltd. (Own Brand: LS VISION). LS VISION is China No.1 IP Camera professional Supplier for Tough Environment. LS VISION always uphold the corporate culture – “Only for Quality Life” and focused on quality and service. Aim to provide top quality security products, professional service and best customer experience.

LS VISION main product include High Quality IP Camera, HD Network Camera, PTZ Camera, AHD Camera, HD-TVI Camera, AHD DVR, TVI DVR, Hybrid Camera Dvr, HD NVR, and WIFI NVR Kits etc.

LS Vision established since 2012, with fast growing, so far we have 20 engineers R&D team, 20 person sales team and 10 marketing team. LS VISION factory has around 30 workers in production line. and the production capacity can be 15,000pcs in each month. LS Vision's products are widely used in many fields, such as banking, public security, energy infrastructure, telecommunication, intelligent-building, and intelligent-transportation.


Now our team is keeping on research new products, Such as 4K H.265 IP Camera, Starlight IP Camera, 360 degree Panoramic IP Camera and body camera.

OEM and ODM service will be provided beyond your imagine.

LS Vision is definitely a worthwhile cooperation for you.
