LSVISION Rohs 2.4G RJ45 2 MP IP 4 Channels Security Recordable Camera System Wireless Camera NVR Kit

  • 1 - 49 Pieces
    $139.95
  • 50 - 99 Pieces
    $132.95
  • >=100 Pieces
    $128.95
Type:
WiFi IP Camera with 4CH NVR
Style:
BULLET CAMERA
Channels:
4
Lead Time:
Quantity(Pieces) 1 - 20 21 - 50 51 - 100 >100
Est. Time(days) 8 12 15 Negotiable
Customization:
Customized logo (Min. Order: 50 Pieces)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
LSVISION
Model Number:
LS-WK6204
Product name:
LS-WK6204 4 channel wireless nvr kit
Bidirectional Talk:
1 CH(Line in,2Vpp,1Kohms)
Network Interface:
1 RJ45 10M / 100M adaptive Ethernet interface
IP Resolution:
Main stream:up to 1920x2048 Auxiliary stream:4CIF
Synchronous Playback:
Up to 4CH
SATA:
1
Network Port:
4
USB:
2 USB 2.0 Interfaces
Playback simultaneously:
1-4 CH optional
Mobile app:
Danale
Supply Ability
Supply Ability:
3000 Piece/Pieces per Week 2.4g wireless camera kit
Packaging & Delivery
Packaging Details
3pc /CTN
CTN size: 690X560X520mm
5000g/pc
Port
Shenzhen
Lead Time :
Quantity(Pieces) 1 - 20 21 - 50 51 - 100 >100
Est. Time(days) 8 12 15 To be negotiated
Video Description
More Recommendation
Product Description

LSVISION Rohs 2.4G RJ45 2 MP IP 4 Channels Security Recordable Camera System Wireless Camera NVR Kit


Key Features:


1.H.265 encoding 4CH 1080P wifi NVR kit

2.802.11b/g/n ;300Mbps;2.4G wireless

3.4CH 1080P@15fps video input and 4CH sync playback

4.Support HDMI/VGA;1 SATA max 6T

5.Support 1 RJ45;2 USB interface;2pcs 5dbi detachable wifi antenna

6.With 1m reticle*1;Power adaptor*5;USB Mouse*1 ;1 network port;

7.With 4pcs 1080P IR bullet cameras, 1/2.7" 2.0MP sensor, 4mm lens, with 5dbi antenna

Specification
Product
H.265 2mp wifi ip camera
Image Sensor
1080P, 2MP CMOS sensor
Min. Illumination
0.1Lux @ (F1.4,AGC ON), 0 Lux with IR
Shutter time
1/25s ~ 1/100,000s
Lens
4mm
Lens Mount
C/M12 (optional)
LED
4pcs Array LED
IR Distance
20 meters
Day& Night
ICR
Wide Dynamic Range
Digital WDR
Digital noise reduction
3D DNR
Image Compression
H.265
Image Frame Rate
32 Kbps ~ 16 Mbps
Resolution
720P(1280*720), VGA(640*480), QVGA(320*240)
Stream
Dual stream
Frame Rate
50Hz: 25fps (1280*720)   60Hz: 30fps (1280*720)
Image Settings
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
4ch wireless nvr
Operating System
Embedded Linux operating system
Image Code Control
Image code quality adjustable, variable bitstream and constant bitstream optional
Dual Stream
Each channel can set main stream and sub stream
Video Standard
1080P/960P
Monitoring Image Quality
1080P(1920*1080) (depends on IP camera)
Image Motion Detection
Each screen can set mutiple detection areas and set 6-level sensitivity (IPC Support)
Recording Playback Quality
4ch 1080P playback simultaneously
Recording Mode
Support manual, auto, dynamic detection, alarm trigger record mode (Partly needs IPC Support)
Backup Way
Support U disk, USB mobile HDD, USB DVD-RW, network storage and backup
Recording Storage
Local HDD, network
Events Trigger
Built-in motion detection, schedule
Notification Method
Alarm, Buzzer, E-mail, FTP
Interface Type
1* SATA interface
Capacity
Without HDD or Built-in 1TB SATA HDD (optional)  Support up to 6TB SATA HDD for update
Standards
IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
Network Interfaces
1* 10/100Mbps Auto MDI/MDIX RJ45 WAN port                                                    3* 10/100Mbps Auto MDI/MDIX RJ45 LAN port                                                    3* 10/100Mbps Auto MDI/MDIX RJ45 LAN port
USB Interface
2* USB 2.0 Port
LED Indicators
Power, Hard Disk, RUN
Antennas
2* 5dBi Detachable Antenna, SMA Connector
Power Supply
DC 12V/3A (Output)
