LS VISION 360 degree panorama h.265 p2p security outdoor cctv ip camera

FOB Reference Price:Get Latest Price
$1,458.00 - $1,596.00 / Piece | 1 Piece/Pieces (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
LS VISION
Model Number:
LS-SPD5300
Sensor:
CMOS
Type:
IP Camera
Video encoding standard:
H.265/H.264/MJPEG Optional
Lens:
2.8mm Fixed Lens
Horizontal Angle of View:
360 degree
Warranty:
2 Years
Color:
White
Certificate:
CE FCC ROHS
Built-in SD card:
Support Max 128G Micro SD/SDHC /SDXC card local storage
Power:
36W
Supply Ability
Supply Ability:
3000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
color box
Port
Shenzhen
Lead Time :
Shipped in 5 days after payment
Key Feature

.  A sensor based on 5 mosaic 360 degree panoramic view;
.  Efficient and economical single mode of installation of industrial grade high quality optical lens;
.  supported by the digital level rotation / vertical rotation / zoom view multiple regions;
.  5x2.0MP@30fps or 10.0MP@30fps resolution;
. By H.265/H.264 High Profile video compression technology, with high compression ratio;
.  ICR infrared filter automatic switching, realize the monitoring day and night;
.  Support Web and client software correction;
.  Support maximum Micro SD/SDHC /SDXC 128G card local storage;
.  To adapt to different temperature and humidity of the outdoor scene monitoring environment;
. Support IP66 grade waterproof and dust, IK10 anti riot grade design


LS VISION  360 degree panorama h.265 p2p security outdoor cctv ip camera
Specification

Specifications

Product model

LS-SPD5200(5x2MP)

LS-SPD5300(5x3MP)

LS-SPD5500(5x5MP)

Media Processor

High-performance Hisilicon DSP

Image Sensor

5*1/1.9" 2MP Pixel can CMOS

5*1/2.8" 3MP Pixel can CMOS

5*1/1.8" 5MP Pixel can CMOS

shutter speed

1/5 second -1/50,000 second

Min illumination

color:0.1Lux @ F1.2 AGC On

black-and-white:0.001Lux @ F1.2 AGC On

color:0.3Lux @ F1.2

black-and-white:0.005Lux@ F1.2

color:0.2Lux @ F1.2 AGC On

black-and-white:0.003Lux @ F1.2 AGC On

Lens

2.8mm Fixed Lens

viewing angle

360 degree

Day&Night

ICR Infrared filter

Encoding standard

Video encoding standard

H.265/H.264/MJPEG Optional

Encoding type

H.265/H.264 Baseline/MainProfile/HighProfile Optional

Audio coding standard

G.711a/G.711u/RAW_PCM Optional

Image index

Max image size

16 Megapixels

/ 5 x 1920x1080 (HDTV)

24 Megapixels

/ 5 x 2048x1520 (HDTV)

40 Megapixels

 / 5 x 2592x1944 (HDTV)

ePTZ

Support digital zoom / PAN / tilt

frame rate

5 x 1920x1080 @ 30fps

5 x 2048x1520 @ 30fps

5 x 2592x1944 @ 30fps

Image set

Brightness, contrast, saturation, sharpness adjustment

Network function

Smart alarm

Motion detection, occlusion alarm, full of memory, the memory fault.

Support protocol

IPv4/IPv6,RTSP/RTP/RTCP,TCP/UDP,HTTP,DHCP,DNS,FTP,DDNS,PPPoE,SMTP,Onvif V2.4

General functions

A key recovery, anti flicker, double stream, heartbeat, password protection

Function interface

network interface

1 RJ45 10M/100M adaptable Ethernet ports

Built-in SD card

Support Max 128G Micro SD/SDHC /SDXC card local storage

Audio input / output

1- channel 3.5 mm audio input (mic input / linear input) / output interface

Alarm input / output

1 channel input / output

General specification

working temperature/humidity

-30℃ ~ 60℃, humidity is less than 95% (no condensation heater).

Power Interface

DC12V±10%,3A

Power

36W

Waterproof Rate

IP66

Vandal-proof Rate

IK10

Dimensions(mm)

281.8 x 228mm

Weight(kg)

5.9








Products Picture

GUI design

Free App IOS Android QR CODE P2P



Our Services

1. Two year quality guarantee
2. OEM service to meet all your need.
3. Popular model will be suggested,keep our customer updated for the information about the products..
4. 7*24 Technical support
NOTE: The RMA code will be given with the response email. Return shipping charges will be the buyer`s responsibility.



   Customers all over the world

     Customers Feedback & Product Certification


   Trading Process

Company Information

Why LS VISION will be your first choice in the market?



1.Shenzhen LS Vision Technology Co., Ltd., established with the purpose of serving the house ware with professional quality products.
2.We have more than years export experience with a turnover more than 16 million US dollars.
3.We win a high reputation with our great ideas of creation and High quality products. LS VISION has exported our products all around the world, like USA, European countries.
4.We are also OEM&ODM manufacturer.
5.We own a professional engineering team and with our own factories to service different need of customers.
6.We believe with the permanent quality and reasonable price and excellent service, we are devoting to built pleasant business relationship with customers from all over the world. LS Vision Technology will be your first choice in the market.



Features  I  ONVIF Compatiable with international Brand CMS



Packaging & Shipping

1.Packaging Details:CTN

2.Shipping Details:dhl, fedex, ups
3.Payment Terms: Paypal , Western Union , T/T

4.Delivery Time: Within 7 working days
